Product Feature
- More cost-effective than traditional ELISA
- High specificity and system reproducibility
- Suitable for diverse sample types
- Low sample volume requirement: 50 µL or less
- Get results same day (6-hour processing time)
- Well-suited for high throughput assays
- Q Analyzer software provides one-step computation
Target Names Available
4-1BB, 6Ckine, ACE, Activin A, ADAMTS1, Adiponectin, ALK-1, Amphiregulin, Angiopoietin-3, ANGPTL1, ANGPTL3, Artemin, Axl, B7-1, BAFF R, Betacellulin, bFGF, BLC, C5a, CCL1, CCL11, CCL17, CCL19, CCL2, CCL20, CCL21, CCL22, CCL24, CCL27, CCL28, CCL3, CCL4, CCL5, CCL6, CCN3, CD105, CD106, CD150, CD152, CD27, CD27 Ligand, CD30, CD30 Ligand, CD32b, CD36, CD40, CD40 Ligand, CD48, CD54, CD6, CD62L, Chemerin, Chordin, Clusterin, CRP, CT-1, CTACK, CTLA-4, CX3CL1, CXCL1, CXCL11, CXCL12 alpha, CXCL15, CXCL16, CXCL4, CXCL9, Cystatin C, DAN, Decorin, DKK-1, DLL4, Dtk, E-Cadherin, EDAR, EGF, Endocan, Endoglin, Eotaxin-1, Eotaxin-2, Epigen, Epiregulin, E-Selectin, Fas, Fas Ligand, Fc gamma RIIB, Fetuin A, Flt-3 Ligand, Fractalkine, Galectin-1, Galectin-3, Galectin-7, Gas 1, Gas 6, G-CSF, GITR, GITR Ligand, GM-CSF, gp130, GPNMB, Granzyme B, Gremlin 1, H60, HAI-1, HGF, HGFR, ICAM-1, IFN-gamma, IFN-gamma R1, IFN-lambda, IGF-1, IGFBP-2, IGFBP-3, IGFBP-5, IGFBP-6, IL-1 alpha, IL-1 beta, IL-1 F11, IL-1 F3, IL-1 R4, IL-1 Ra, IL-10, IL-11, IL-12 p40, IL-12 p40/p70, IL-12 p70, IL-13, IL-15, IL-17, IL-17A, IL-17B, IL-17B R, IL-17C, IL-17E, IL-17F, IL-1F1, IL-1F2, IL-2, IL-2 R alpha, IL-20, IL-21, IL-22, IL-23, IL-28, IL-3, IL-3 R beta, IL-33, IL-4, IL-5, IL-6, IL-6 R, IL-7, IL-7 R alpha, IL-9, I-TAC, JAM-A, KC, KIM-1, Kremen-1, Leptin, Leptin R, Limitin, Lipocalin-2, LIX, LOX-1, L-Selectin, Lungkine, Lymphotactin, MAdCAM-1, Marapsin, MBL-2, MCP-1, MCP-5, M-CSF, MDC, Meteorin, MFG-E8, MIG, MIP-1 alpha, MIP-1 beta, MIP-1 gamma, MIP-2, MIP-3 alpha, MIP-3 beta, MMP-10, MMP-2, MMP-3, MPIF-2, Neprilysin, NGAL, Nope, NOV, Osteoactivin, Osteopontin, Osteoprotegerin, OX40 Ligand, P-Cadherin, PDGF-AA, Pentraxin-3, Periostin, Persephin, Platelet Factor 4, PlGF-2, Progranulin, Prolactin, Pro-MMP-9, Prostasin, P-Selectin, RAGE, RANTES, Renin 1, Resistin, SCF, SDF-1 alpha, sFRP-3, SLAM, Sonic Hedgehog N-Terminal, SPP1, SR-B3, sTNFRI, sTNFRII, TACI, TARC, TCA-3, TCK-1, TECK, Testican 3, TGF beta 1, Thrombopoietin, TIM-1, TIMP-1, TNF alpha, TNF RI, TNF RII, TNFRII, TNFRSF11B, TNFRSF12, TNFRSF13B, TNFRSF18, TNFRSF19, TNFRSF1A, TNFRSF1B, TNFRSF5, TNFRSF6, TNFRSF7, TNFRSF8, TNFSF10, TNFSF11, TNFSF12, TNFSF18, TNFSF4, TNFSF5, TNFSF6, TNFSF7, TNFSF8, TPO, TRAIL, TRANCE, TREM-1, TREML1, TROY, Tryptase epsilon, TSG-14, TSLP, TWEAK, TWEAK R, VCAM-1, VEGF-A, VEGF-B, VEGF-D, VEGFR1, VEGF-R2, VEGFR3, XCL1
Target Species
Mouse
Application Notes
Suggested Application
Multiplexed Protein Detection; Biomarker Screening; Identifying Key Factors; Confirming Biological Process; Biomarker Validation; Validation of Antibody Array Results; Quantitative Protein Detection; Establishing Normal Range; Isotyping
Kit Components
- Custom Quantibody® Mouse Array Slides
- Blocking Buffer
- Wash Buffer 1
- Wash Buffer 2
- Lyophilized Standard Mix
- Biotinylated Detection Antibody Cocktail
- Streptavidin-Conjugated Fluor
- Slide Washer/Dryer
- Adhesive Plastic Strips
- Manual
Other Materials Required
- Distilled or deionized water
- Small plastic boxes or containers
- Pipettors, pipette tips and other common lab consumables
- Orbital shaker or oscillating rocker
- Aluminum foil
- Gene microarray scanner or similar laser fluorescence scanner
View Compatible Laser ScannersDon't have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays!
Learn MoreProtocol Outline
- Dry the glass slide
- Prepare Standards
- Block array surface
- Incubate with Samples and Standards
- Incubate with Biotinylated Detection Antibody Cocktail
- Incubate with Streptavidin-Conjugated Fluor
- Disassemble the glass slide
- Scan with a gene microarray laser scanner
- Perform densitometry and analysis
Storage/Stability
For best results, store the entire kit frozen at -20°C upon arrival. Stored frozen, the kit will be stable for at least 6 months which is the duration of the product warranty period. Once thawed, store array slide(s), standard mix, detection antibody cocktail, and Cy3-Conjugated Streptavidin at -20°C and all other reagents undiluted at 4°C for no more than 3 months.
