Product Description

Specifications

Size	2 Plate Kit, 4 Plate Kit, 6 Plate Kit
Estimated Lead Time	1-2 business days
Species	Human
Compatible Sample Types	Extracted RNA
Quantitative/Semi-Quantitative	Quantitative
Number of Targets Detected	90
Solid Support	96-Well PCR Plate
Method Of Detection	Real-Time RT-PCR
Research Area	Aging, Cancer biology, Immunology, Neurodegenerative disorders
Shipping Type	Dry ice (additional shipping fee)
Storage	-20°C

Introduction

Immune checkpoints are regulatory molecules that control the magnitude and duration of immune responses. Dysregulation of immune checkpoint signaling is associated with cancer, chronic infection, autoimmune disease, and transplant rejection, making the expression and regulation of these genes important for studying immune balance and precision immunotherapy.

Product Features

SYBR Green-based qPCR array for simultaneous expression profiling
90 rigorously validated, highly specific primer pairs
Includes six controls: three reference genes (INC) for normalization, a genomic DNA control (GDC), a positive PCR control (PC), and a negative control (NC)
Simple workflow — just add cDNA and qPCR master mix
High-quality results in as little as two hours

Array Content

Simultaneous profiling of 90 validated genes involved in immune checkpoint signaling, immune activation, immune suppression, and immune regulation, plus six on-plate controls.

Format Selection / Instrument Key

Select the array plate format that matches your real-time PCR instrument:

Plate A: ABI 5700, ABI 7000, ABI 7300, ABI 7500, ABI 7700
Plate B: ABI 7500 Fast, ABI 7900 HT Fast, ABI StepOnePlus, ABI ViiA 7 Fast, Bio-Rad CFX Connect
Plate C: Roche LightCycler 96, Roche LightCycler 480 (96-well)

Kit Components

96-Well Array Plate(s), preloaded with validated paired primers (2 µL/well)
2X qPCR Master Mix with Hot Start Taq
96-Well Plate Sealing Film

Storage/Stability

Store the kit at -20°C for up to 12 months prior to opening. Avoid repeated freeze-thaw cycles.

Product Use

For research use only. Not for use in clinical or in vitro diagnostic procedures.
