Product Features
- More cost-effective than traditional ELISA
- High specificity and system reproducibility
- Suitable for diverse sample types
- Low sample volume requirement: 50 µL or less
- Get results same day (6-hour processing time)
- Well-suited for high throughput assays
- Q Analyzer software provides one-step computation
Target Names
| Scroll over each target protein for more information |
|---|
Eotaxin-1
(CCL11) | Erythropoietin- Gene Symbol: EPO
- Gene ID: 397249
- Accession #: P49157
| FGF-21- Gene Symbol: FGF21
- Gene ID: 100302504
- Accession #: C6JWG4
| Galectin-9 | IFN-beta- Gene Symbol: interferon-beta-1 IFN-beta IFNB IFNB1 interferon-beta/ poIFN-beta
- Accession #: Q29412
|
IGF-2- Gene Symbol: IGF2
- Gene ID: 396916
- Accession #: P23695
| IL-21- Gene Symbol: IL21
- Gene ID: 403123
- Accession #: Q76LU6
| IL-28B- Gene Symbol: IL28B
- Gene ID: 100310828
- Accession #: D0FHA1
| PLGF-2- Gene Symbol: PlGF
- Accession #: Q58IV6
| SCF- Gene Symbol: KITLG MGF
- Gene ID: 100626805 397509
- Accession #: Q29030
|
Application Notes
Suggested Application
- Multiplexed Protein Detection
- Biomarker Screening
- Identifying Key Factors
- Confirming Biological Process
- Biomarker Validation
- Validation of Antibody Array Results
- Quantitative Protein Detection
- Establishing Normal Range
Kit Components
- Porcine Cytokine Array Q5 Slide/s
- Blocking Buffer
- Wash Buffer 1
- Wash Buffer 2
- Lyophilized Standard Mix
- Biotinylated Detection Antibody Cocktail
- Streptavidin-Conjugated Fluor
- Slide Washer/Dryer
- Adhesive Plastic Strips
- Manual
Other Materials Required
- Distilled or deionized water
- Small plastic boxes or containers
- Pipettors, pipette tips and other common lab consumables
- Orbital shaker or oscillating rocker
- Aluminum foil
- Gene microarray scanner or similar laser fluorescence scanner
View Compatible Laser ScannersDon't have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays!
Learn MoreProtocol Outline
- Dry the glass slide
- Prepare Standards
- Block array surface
- Incubate with Samples and Standards
- Incubate with Biotinylated Detection Antibody Cocktail
- Incubate with Streptavidin-Conjugated Fluor
- Disassemble the glass slide
- Scan with a gene microarray laser scanner
- Perform densitometry and analysis
Storage/Stability
For best results, store the entire kit frozen at -20°C upon arrival. Stored frozen, the kit will be stable for at least 6 months which is the duration of the product warranty period. Once thawed, store array slide(s), standard mix, detection antibody cocktail, and Cy3-Conjugated Streptavidin at -20°C and all other reagents undiluted at 4°C for no more than 3 months.
